EN 10216-5 1.4404/316L Stainless Steel Seamless Tube Austenitic Chrome Nickel Steel for Corrosive Applications

Datos del producto:

Lugar de origen:	Porcelana
Nombre de la marca:	YUHONG
Certificación:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Número de modelo:	EN 10216-5 1.4404

Pago y Envío Términos:

Cantidad de orden mínima:	500 kgs
Precio:	Negociable
Detalles de empaquetado:	Caja de madera de captilla / caja de hierro / paquete con tapa de plástico
Tiempo de entrega:	15-20 días
Condiciones de pago:	LC, T/T
Capacidad de la fuente:	800 toneladas por mes

Contacto

Todos los productos

Tubo sin costura de acero inoxidable (308)

Tubo inconsútil de acero inoxidable (297)

Tubería de acero inoxidable a dos caras (132)

Tubo de acero inoxidable del duplex (33)

Tubo de aguja (134)

Tubo de aleta (672)

intercambiador de calor (20)

tubo del cambiador de calor (443)

Envase de tubos para intercambiadores de calor (40)

Cambiador de calor Tubesheet (117)

bafle del cambiador de calor (37)

Frío de aire (9)

Contenedor de presión (4)

tubo soldado con autógena de acero inoxidable (58)

Tubo soldado con autógena del acero inoxidable (120)

Tubo de la aleación de níquel (266)

Tubo de la aleación de níquel (92)

Tubo de la aleación de cobre (240)

Tubo del acero de aleación (204)

Tubo del titanio (15)

tubo recocido brillante (155)

Tubo de caldera (151)

colocación de acero (826)

Reborde de acero (615)

Las demás (401)

Partes de revestimiento (7)

Descripción detallada del producto

Estándar:	EN 10216-5	Grado material:	1.4404/316L (UNS S31603)
Tipo de producto:	TUBO SIN COSTURA	Material:	Acero inoxidable AUSTENÍTICO
Aplicación:	Equipos químicos, aplicaciones marinas	Rango de tamaño:	DE 6 mm-610 mm, PESO 1 mm-50 mm
Resaltar:	EN 10216-5 316L stainless steel tube , Austenitic chrome nickel steel tube , Seamless stainless tube for corrosive applications

EN 10216-5 1.4404/316L Stainless Steel Seamless Tube Austenitic Chrome Nickel Steel for Corrosive Applications

YUHONG GROUP is a specialized manufacturer with 35 years of industrial experience and a global presence spanning 85 countries, dedicated to producing high-performance stainless steel tubes for critical applications. Our EN 10216-5 1.4404/316L stainless steel seamless tubes are manufactured to meet the most demanding European quality standards, offering excellent corrosion resistance and reliability for chemical processing, marine environments, and other challenging industrial applications.

Chemical Composition of Steel Grade 1.4404 (X2CrNiMo17-12-2)

Element	Requirement (%)
Carbon (C), max	0.03
Silicon (Si), max	1
Manganese (Mn), max	2
Phosphorus (P), max	0.04
Sulfur (S), max	0.015
Nitrogen (N), max	0.11
Chromium (Cr)	16.50 - 18.50
Molybdenum (Mo)	2.00 - 2.50
Nickel (Ni)	10.00 - 13.00

Mechanical Properties of Steel Grade 1.4404 (X2CrNiMo17-12-2)

Property	Specification / Requirement	Condition / Notes
Steel Name / Grade	X2CrNiMo17-12-2 / 1.4404	Austenitic Stainless Steel (AISI 316L)
0.2% Proof Strength, Rp0.2, min	190 MPa
1.0% Proof Strength, Rp1.0, min	225 MPa
Tensile Strength, Rm	490 - 690 MPa
Elongation, A, min	40% (Longitudinal) / 30% (Transverse)
Impact Energy, KV, min	100 J (Room Temp) / 60 J (-196°C)	Average absorbed energy
Solution Annealing Temperature	1020 - 1120 °C	Reference heat treatment condition
Cooling Method	Water, Air
Resistance to Intergranular Corrosion	Yes (Pass)	Per EN ISO 3651-2

Austenitic Stainless Steels Grade Designation Cross-Reference

Steel Name (DIN/EN)	Steel Number (Mat. No.)	Common UNS Equivalent	Common Trade Name / AISI
X2CrNi18-9	1.4307	S30403	304L
X2CrNi19-11	1.4306	S30403	304L
X2CrNiN18-10	1.4311	S30453	304LN
X5CrNi18-10	1.4301	S30400	304
X6CrNiTi18-10	1.4541	S32100	321
X6CrNiNb18-10	1.455	S34700	347
X2CrNiMo17-12-2	1.4404	S31603	316L
X5CrNiMo17-12-2	1.4401	S31600	316
X6CrNiMoTi17-12-2	1.4571	S31635	316Ti
X2CrNiMoN17-13-3	1.4429	S31653	316LN

EN 10216-5 1.4404/316L Stainless Steel Seamless Tube - Application Advantages

1. Excellent Corrosion Resistance
The 1.4404/316L austenitic chrome-nickel stainless steel composition provides outstanding resistance to a wide range of corrosive media, making it ideal for chemical processing, marine environments, and other aggressive applications.
2. High Mechanical Strength and Durability
Manufactured as seamless tubes according to EN 10216-5 standards, these tubes offer superior structural integrity and long-term performance under high-pressure and temperature conditions.
3. Leak-Proof and Reliable Performance
The seamless construction eliminates weld seams, reducing potential leak points and ensuring enhanced safety and reliability in critical piping systems.
4. Hygienic and Easy to Clean
The smooth internal surface and non-porous material make these tubes suitable for sanitary applications in food, pharmaceutical, and biotechnology industries.
5. Wide Temperature Adaptability
Maintains excellent mechanical properties and corrosion resistance across a broad temperature range, from cryogenic conditions to elevated temperatures up to 400°C.
6. Cost-Effective Maintenance
The combination of corrosion resistance and durability significantly reduces maintenance requirements and extends service life, providing long-term cost savings.
