SUS304 Stainless Steel Medical Hypodermic Capillary Tube For Injection 10G-34G ISO9626

Datos del producto:

Lugar de origen:	Porcelana
Nombre de la marca:	YUHONG
Certificación:	ISO13485:2016
Número de modelo:	10G-34G

Pago y Envío Términos:

Cantidad de orden mínima:	50 kgs
Precio:	Negociable
Detalles de empaquetado:	Cajas de madera
Tiempo de entrega:	15 - 45 días de trabajo
Condiciones de pago:	T/T, LC/C
Capacidad de la fuente:	13 mil millones de piezas por año

Contacto

Todos los productos

Tubo sin costura de acero inoxidable (308)

Tubo inconsútil de acero inoxidable (297)

Tubería de acero inoxidable a dos caras (132)

Tubo de acero inoxidable del duplex (33)

Tubo de aguja (134)

Tubo de aleta (672)

intercambiador de calor (20)

tubo del cambiador de calor (443)

Envase de tubos para intercambiadores de calor (40)

Cambiador de calor Tubesheet (117)

bafle del cambiador de calor (37)

Frío de aire (9)

Contenedor de presión (4)

tubo soldado con autógena de acero inoxidable (58)

Tubo soldado con autógena del acero inoxidable (120)

Tubo de la aleación de níquel (266)

Tubo de la aleación de níquel (92)

Tubo de la aleación de cobre (240)

Tubo del acero de aleación (204)

Tubo del titanio (15)

tubo recocido brillante (155)

Tubo de caldera (151)

colocación de acero (826)

Reborde de acero (615)

Las demás (401)

Partes de revestimiento (7)

Descripción detallada del producto

Estándar de tubo capilar:	ISO9626:2016 (estándar médico), ASTM A269 (estándar industrial)	Materia prima del tubo capilar:	Grado médico SUS304
Diámetro exterior del tubo capilar:	10G-34G	Espesor de la pared del tubo capilar:	RW, TW, ETW, UTW
Longitud del tubo capilar:	1M, 2M o cortado a la longitud del tubo de la aguja	Extremos del tubo capilar:	Extremos lisos, extremos biselados
Superficie del tubo capilar:	Pulido	Aplicaciones de Tubos Capilares:	Agujas médicas, catéteres médicos, dispositivos quirúrgicos, instrumentos de precisión, etc.
Resaltar:	SUS304 stainless steel hypodermic tube , medical capillary tube for injection , ISO9626 needle tube 10G-34G

SUS304 Stainless Steel Medical Hypodermic Capillary Tube For Injection 10G-34G ISO9626

A Stainless Steel Medical Hypodermic Tube is a precision-engineered, cold-drawn, welded stainless steel tube specifically manufactured for medical and surgical applications. This medical capillary tube is made by SUS304 (AISI 304) stainless steel, which is an austenitic chromium-nickel alloy known for its excellent corrosion resistance, formability, and biocompatibility. The SUS304 medical stainless steel capillary tubes are produced to meet the stringent requirements of ISO9626:2016 international standard, which governs dimensions, tolerances, material composition, mechanical properties, and surface finish. The tube size generally ranges from 10G to 34G, and the wall thickness can be regular wall, thin wall, extra-thin wall, etc. In addition to standard tubes, we can also customize non-standard tubes based on the client’s drawings. These medical grade capillary tubes are the primary raw material for manufacturing hypodermic needles, cannula, biopsy needles, catheter mandrels, and other minimally invasive surgical instruments.

The Main Advantages Of SUS304 Medical Capillary Tubes:

Biocompatibility And Safety: SUS304 is non-toxic, non-pyrogenic, and resistant to bodily fluids, ensuring patient safety and compliance with medical regulations.
Superior Corrosion Resistance
Good Mechanical Performance: Excellent combination of high tensile strength and ductility. Allows for precise point grinding (beveling).
Exceptional Surface Finish: ultra-smooth internal and external finish. This minimizes friction during insertion, reduces patient pain, prevents clot adhesion, and ensures accurate fluid flow.
Dimensional Precision & Consistenc
Weldability And Formability

Regular Sizes:

Outer Diameter		OD Range		Inner Diameter Min.
Gauge	Norminal	Min.	Max.	RW	TW	ETW
-	0.15	-	-	-	-	-
34G	0.18	0.178	0.191	0.064	0.091	0.105
33G	0.2	0.203	0.216	0.089	0.105	0.125
32G	0.23	0.229	0.241	0.089	0.105	0.125
31G	0.25	0.254	0.267	0.114	0.125	0.146
30G	0.30	0.298	0.320	0.133	0.165	0.190
29G	0.33	0.324	0.351	0.133	0.190	0.240
28G	0.36	0.349	0.370	0.133	0.190	-
27G	0.40	0.400	0.420	0.184	0.241	-
26G	0.45	0.440	0.470	0.232	0.292	-
25G	0.50	0.500	0.530	0.232	0.292	-
24G	0.55	0.550	0.580	0.280	0.343	-
23G	0.60	0.600	0.673	0.317	0.370	0.460
22G	0.70	0.698	0.730	0.390	0.440	0.522
21G	0.80	0.800	0.830	0.490	0.547	0.610
20G	0.90	0.860	0.920	0.560	0.635	0.687
19G	1.10	1.030	1.100	0.648	0.750	0.850
18G	1.20	1.200	1.300	0.790	0.910	1.041
17G	1.40	1.400	1.510	0.950	1.156	1.244
16G	1.60	1.600	1.690	1.100	1.283	1.390
15G	1.80	1.750	1.900	1.300	1.460	1.560
14G	2.10	1.950	2.150	1.500	1.600	1.727
13G	2.40	2.300	2.500	1.700	1.956	-
12G	2.70	2.650	2.850	1.950	2.235	-
11G	3.00	2.950	3.150	2.200	2.464	-
10G	3.40	3.300	3.500	2.500	2.819	-

Applications:

A. Medical & Surgical Applications (Primary):

Hypodermic Needles: The core application for injections (subcutaneous, intramuscular, intravenous).
IV Cannulas: Peripheral venous catheters.
Biopsy Needles: For tissue sampling (e.g., core biopsy).
Specialty Needles: Spinal (epidural), orthopedic, ophthalmic, and dialysis needles.
Catheter Mandrels/Introducers: As the stiffening component for guiding flexible catheters.
Surgical Instruments: Components for laparoscopic tools, guide wires, and suture needles.
